The SKT 350 (Sequential Kinking Terminal) is an energy absorbing tangent terminal. The SKT is 50′-0″ long and has 8 breakaway posts. NCHRP 350 APPROVED! During head-on impacts, the SKT head slides over the W-beam guardrail. The rail is sequentially kinked or bent as it moves through the head. The kinked guardrail exits the head safely and the vehicle is brought to a controlled stop. When impacted along the side within the length-of-need, the SKT functions like guardrail. The errant vehicle is safely redirected back toward its original travel path.
Soil Plate Option:
The FHWA now allows the 4′-6″ long foundation tubes at posts 3 & 4 or posts 3 – 8 to be installed without the soil plates. This design is optional and the contract plans must be followed. See FAQ’s for additional information.
Benefits and Features
- The only component different from the FLEAT is the impact head. This greatly reduces inventory requirements.
- The forces required to push the impact head down the rail are lower than other tangent end terminals.
- The impact head weighs less than 175 pounds. The high strength steel construction and lower impact forces results in a better performing design.
- The impact head is significantly easier to remove from the rail compared to competitive systems.
- The refined design over older technology improves the impact performance efficiency. The longer impact head and improved cable anchor bracket results in a better terminal.
- The SKT is available from multiple distributors. This means the end of sole source supply.
- The SKT is available in a 2, 4, or 8 foundation tube option.
- Fits a wide range of applications:
- Wood or Steel Posts
- Test Level 2 and 3 Speed
- Also Available: SKT-LITE, shortened (37′ 6″ long) system with wood or steel posts (SKT-LITE Drawing).
A Hinged Steel Post Option is available for the SKT. The drawing is available in the Downloads section of this page.
SKT-SP Standard Post System
The same SKT already in use all across America
- Enhanced upper and lower hinged Post #1
- Hinged W6 Post #2, no ground strut
- Cost savings for Post #3 and beyond:
- Generic standard W6 steel guardrail posts
- Standard W-Beam rail sections
- Simplified installation and maintenance
- SKT Wood Post Installation Manual
- SKT / FLEAT Test Level 2 Supplemental Installation Manual
- SKT-SP Standard Post System Drawing
- SKT Assembly Drawing For Hinged Post
- SKT Steel Post Installation Manual
- SKT-SP and FLEAT-SP Steel Post Installation Manual
- April 2, 1997 SKT Approval
- June 10, 1998 Foundation Tube and Blockout Options
- August 27, 1999 SKT & FLEAT Steel Post Approval
- February 4, 2000 SKT Test Level 2 Approval
- March 23, 2001 SKT Eliminating Soil Plates
From Tubes 3 Through 8
- October 30, 2002 SKT Hinged Steel Post Approval
- July 14, 2004 SKT LITE Shortened 37′-6″ Long System
With Wood or Steel Posts
- August 20, 2004 SKT & FLEAT Steel Post Hinged
With Single 3/4″ Bolt.
- June 1, 2008 SKT Universal Posts
- September 17, 2008 SKT-SP Standard Post System
